公制牙系列絲攻 M/MF
公制粗牙系列
| Size 規格 |
Pitch 牙距 mm |
Thread Length 螺紋有效長 mm |
Shank Diameter 柄徑 mm |
Overall Length 全長 mm |
Wedding焊接(W)/ Tungsten全鎢(T) |
| M1 | 0.25 | 5 | 3 | 50 | T |
| M1.1 | 0.25 | 6 | 3 | 50 | T |
| M1.2 | 0.25 | 6 | 3 | 50 | T |
| M1.4 | 0.3 | 8 | 3 | 50 | T |
| M1.6 | 0.35 | 10 | 3 | 50 | T |
| M1.7 | 0.35 | 10 | 3 | 50 | T |
| M1.8 | 0.35 | 10 | 3 | 50 | T |
| M2 | 0.4 | 12 | 3 | 50 | T |
| M2.2 | 0.45 | 12 | 3 | 50 | T |
| M2.3 | 0.4 | 12 | 3 | 50 | T |
| M2.5 | 0.45 | 13 | 3 | 50 | T |
| M2.6 | 0.45 | 13 | 3 | 50 | T |
| M3 | 0.5 | 15 | 4 | 50 | T |
| M3 | 0.6 | 15 | 4 | 50 | T |
| M3.5 | 0.6 | 15 | 4 | 50 | T |
| M4 | 0.7 | 17 | 5 | 50 | T |
| M4 | 0.75 | 17 | 5 | 50 | T |
| M4.5 | 0.75 | 18 | 5 | 50 | T |
| M5 | 0.8 | 18 | 5.5 | 50 | T |
| M5 | 0.9 | 18 | 5.5 | 50 | T |
| M6 | 1.0 | 20 | 6 | 50 | T |
| M7 | 1.0 | 20 | 6.2 | 50 | T |
| M8 | 1.25 | 22 | 6.2 | 50 | T |
| M9 | 1.25 | 24 | 7 | 75 | T |
| M10 | 1.5 | 24 | 7 | 75 | T |
| M11 | 1.5 | 24 | 8 | 75 | T |
| M12 | 1.75 | 25 | 8.5 | 75 | T |
| M14 | 2.0 | 28 | 10.5/22.225 | 85 | W |
| M16 | 2.0 | 30 | 12.5/22.225 | 85 | W |
| M18 | 2.5 | 30 | 14/22.225 | 85 | W |
| M20 | 2.5 | 30 | 15/22.225 | 85 | W |
| M22 | 2.5 | 40 | 17/22.225 | 85 | W |
| M24 | 3.0 | 40 | 19/22.225 | 85 | W |
| M27 | 3.0 | 40 | 20/22.225 | 85 | W |
| M30 | 3.5 | 40 | 20/22.225 | 85 | W |
| M33 | 3.5 | 40 | 25/22.225 | 85 | W |
| M36 | 4.0 | 40 | 28/22.225 | 85 | W |
| M39 | 4.0 | 40 | 30/22.225 | 85 | W |
| M42 | 4.5 | 40 | 32/31.75 | 90 | W |
| M45 | 4.5 | 40 | 32/31.75 | 90 | W |
| M48 | 5.0 | 40 | 32/31.75 | 90 | W |
| M52 | 5.0 | 45 | 32/31.75 | 90 | W |
| M56 | 5.5 | 45 | 32/31.75 | 90 | W |
| M60 | 5.5 | 45 | 32/31.75 | 90 | W |
| M64 | 6.0 | 45 | 32/31.75 | 90 | W |
| M68 | 6.0 | 45 | 32/31.75 | 90 | W |
| M72 | 6.0 | 45 | 32/31.75 | 90 | W |
| M76 | 6.0 | 45 | 32/31.75 | 90 | W |
公制細牙系列
| Size 規格 |
Pitch 牙距 mm |
Thread Length 螺紋有效長 mm |
Shank Diameter 柄徑 mm |
Overall Length 全長 mm |
Wedding焊接(W)/ Tungsten全鎢(T) |
| M1 | 0.2 | 5 | 3 | 50 | T |
| M1.1 | 0.2 | 5 | 3 | 50 | T |
| M1.2 | 0.2 | 5 | 3 | 50 | T |
| M1.4 | 0.2 | 5 | 3 | 50 | T |
| M1.6 | 0.2 | 5 | 3 | 50 | T |
| M1.7 | 0.2 | 5 | 3 | 50 | T |
| M1.8 | 0.2 | 5 | 3 | 50 | T |
| M2 | 0.25 | 6 | 3 | 50 | T |
| M2.2 | 0.25 | 6 | 3 | 50 | T |
| M2.3 | 0.25 | 6 | 3 | 50 | T |
| M2.5 | 0.35 | 10 | 3 | 50 | T |
| M2.6 | 0.35 | 10 | 3 | 50 | T |
| M3 | 0.35 | 10 | 4 | 50 | T |
| M3.5 | 0.35 | 10 | 4 | 50 | T |
| M4 | 0.35 | 12 | 5 | 52 | T |
| M4 | 0.5 | 15 | 5 | 52 | T |
| M4.5 | 0.5 | 15 | 5 | 52 | T |
| M5 | 0.5 | 15 | 5.5 | 52 | T |
| M5 | 0.75 | 15 | 5.5 | 52 | T |
| M5.5 | 0.5 | 15 | 5.5 | 52 | T |
| M6 | 0.5 | 20 | 6 | 62 | T |
| M6 | 0.75 | 20 | 6 | 62 | T |
| M7 | 0.5 | 20 | 6.2 | 62 | T |
| M7 | 0.75 | 20 | 6.2 | 62 | T |
| M8 | 0.5 | 20 | 6.2 | 70 | T |
| M8 | 0.75 | 20 | 6.2 | 70 | T |
| M8 | 1.0 | 20 | 6.2 | 70 | T |
| M9 | 0.75 | 20 | 7 | 62 | T |
| M9 | 1.0 | 20 | 7 | 70 | T |
| M10 | 0.5 | 20 | 7 | 75 | T |
| M10 | 0.75 | 20 | 7 | 75 | T |
| M10 | 1.0 | 20 | 7 | 75 | T |
| M10 | 1.25 | 20 | 7 | 75 | T |
| M11 | 0.75 | 20 | 8 | 75 | T |
| M11 | 1.0 | 30 | 8 | 75 | T |
| M12 | 0.5 | 30 | 8.5 | 75 | T |
| M12 | 1.0 | 30 | 8.5 | 75 | T |
| M12 | 1.25 | 30 | 8.5 | 75 | T |
| M14 | 1.0 | 30 | 10.5/22.225 | 75 | W |
| M14 | 1.25 | 30 | 10.5/22.225 | 75 | W |
| M14 | 1.5 | 30 | 10.5/22.225 | 75 | W |
| M15 | 1.0 | 30 | 10.5/22.225 | 75 | W |
| M15 | 1.5 | 30 | 10.5/22.225 | 75 | W |
| M16 | 1.0 | 30 | 12.5/22.225 | 75 | W |
| M16 | 1.5 | 30 | 12.5/22.225 | 75 | W |
| M17 | 1.0 | 30 | 13/22.225 | 80 | W |
| M17 | 1.5 | 30 | 13/22.225 | 80 | W |
| M18 | 1.0 | 30 | 14/22.225 | 85 | W |
| M18 | 1.25 | 30 | 14/22.225 | 85 | W |
| M18 | 1.5 | 30 | 14/22.225 | 85 | W |
| M18 | 2.0 | 30 | 14/22.225 | 85 | W |
| M20 | 1.0 | 30 | 15/22.225 | 85 | W |
| M20 | 1.5 | 30 | 15/22.225 | 85 | W |
| M22 | 1.0 | 40 | 17/22.225 | 85 | W |
| M22 | 1.5 | 40 | 17/22.225 | 85 | W |
| M22 | 2.0 | 40 | 17/22.225 | 85 | W |
| M24 | 1.0 | 40 | 19/22.225 | 85 | W |
| M24 | 1.5 | 40 | 19/22.225 | 85 | W |
| M24 | 2.0 | 40 | 19/22.225 | 85 | W |
| M25 | 1.0 | 40 | 19/22.225 | 85 | W |
| M25 | 1.5 | 40 | 19/22.225 | 85 | W |
| M25 | 2.0 | 40 | 19/22.225 | 85 | W |
| M26 | 1.5 | 40 | 20/22.225 | 85 | W |
| M27 | 1.5 | 40 | 20/22.225 | 85 | W |
| M27 | 2.0 | 40 | 20/22.225 | 85 | W |
| M28 | 1.5 | 40 | 20/22.225 | 85 | W |
| M28 | 2.0 | 40 | 20/22.225 | 85 | W |
| M30 | 1.0 | 40 | 20/22.225 | 85 | W |
| M30 | 1.5 | 40 | 20/22.225 | 85 | W |
| M30 | 2.0 | 40 | 20/22.225 | 85 | W |
| M30 | 3.0 | 40 | 20/22.225 | 85 | W |
| M32 | 1.5 | 40 | 20/22.225 | 85 | W |
| M32 | 2.0 | 40 | 20/22.225 | 85 | W |
| M33 | 1.5 | 40 | 25/22.225 | 85 | W |
| M33 | 2.0 | 40 | 25/22.225 | 85 | W |
| M33 | 3.0 | 40 | 25/22.225 | 85 | W |
| M35 | 1.5 | 40 | 26/22.225 | 85 | W |
| M36 | 1.5 | 40 | 28/22.225 | 85 | W |
| M36 | 2.0 | 40 | 28/22.225 | 85 | W |
| M36 | 3.0 | 40 | 28/22.225 | 85 | W |
| M38 | 1.5 | 40 | 28/22.225 | 85 | W |
| M38 | 2.0 | 40 | 28/22.225 | 85 | W |
| M39 | 1.5 | 40 | 30/22.225 | 85 | W |
| M39 | 2.0 | 40 | 30/22.225 | 85 | W |
| M39 | 3.0 | 40 | 30/22.225 | 85 | W |
| M40 | 1.5 | 40 | 30/22.225 | 85 | W |
| M40 | 2.0 | 40 | 30/22.225 | 85 | W |
| M40 | 3.0 | 40 | 30/22.225 | 85 | W |
| M42 | 1.5 | 40 | 32/31.75 | 90 | W |
| M42 | 2.0 | 40 | 32/31.75 | 90 | W |
| M42 | 3.0 | 40 | 32/31.75 | 90 | W |
| M42 | 4.0 | 40 | 32/31.75 | 90 | W |
| M45 | 1.5 | 40 | 32/31.75 | 90 | W |
| M45 | 2.0 | 40 | 32/31.75 | 90 | W |
| M45 | 3.0 | 40 | 32/31.75 | 90 | W |
| M48 | 1.5 | 40 | 32/31.75 | 90 | W |
| M48 | 2.0 | 40 | 32/31.75 | 90 | W |
| M48 | 3.0 | 40 | 32/31.75 | 90 | W |
| M48 | 4.0 | 40 | 32/31.75 | 90 | W |
| M50 | 1.5 | 40 | 32/31.75 | 90 | W |
| M50 | 3.0 | 40 | 32/31.75 | 90 | W |
| M52 | 2.0 | 45 | 32/31.75 | 90 | W |
| M52 | 3.0 | 45 | 32/31.75 | 90 | W |
| M56 | 2.0 | 45 | 32/31.75 | 90 | W |
| M56 | 4.0 | 45 | 32/31.75 | 90 | W |
| M60 | 2.0 | 45 | 32/31.75 | 95 | W |
| M60 | 4.0 | 45 | 32/31.75 | 95 | W |
| M62 | 2.0 | 45 | 32/31.75 | 95 | W |
| M64 | 2.0 | 45 | 32/31.75 | 95 | W |
| M64 | 3.0 | 45 | 32/31.75 | 95 | W |
| M64 | 4.0 | 45 | 32/31.75 | 95 | W |
找不到想要的規格?快點來電洽詢!
